How to Create a Compass in Android Code – Tutorial and Source Code

android compass code example

Today I’m going to share a very simple compass in android code that you can use whenever you are creating an application with a compass feature.

It’s good to see the most devices nowadays has a motion sensor capability to make a compass run.

Unfortunately, there are still some android devices (like Huawei Y300 and Lenovo P700i) does not have full support of motions sensors so this code will not work for them.

We will cover the following in this post:

1.0 Android Compass Video Demo
2.0 Compass App Needed Files
3.0 Complete Compass in Android Code
3.1 MainActivity.java
3.2 activity_main.xml
3.3 Some Notes
4.0 Download Source Code
5.0 Further Readings

1.0 Compass in Android Code Video Demo

Our code for today will run just like the following video.

2.0 Compass App Needed Files

You need to create your own compass image. For this example, I’m using a stock photo. Your image must be a PNG with transparent background, do not use this jpg file I used. Please note that the “north” must be at the top part of the image.

compass in android code example

We will also need the two main code files seen in the complete code below.

3.0 Complete Android Compass Code

3.1 MainActivity.java where all the magic happens. The SensorManager was initialized in the onCreate() method and it was being moved or animated using the onSensorChanged() method.

package com.example.compassapp;

import android.app.Activity;
import android.hardware.Sensor;
import android.hardware.SensorEvent;
import android.hardware.SensorEventListener;
import android.hardware.SensorManager;
import android.os.Bundle;
import android.view.animation.Animation;
import android.view.animation.RotateAnimation;
import android.widget.ImageView;
import android.widget.TextView;

public class MainActivity extends Activity implements SensorEventListener {

    // define the display assembly compass picture
    private ImageView image;

    // record the compass picture angle turned
    private float currentDegree = 0f;

    // device sensor manager
    private SensorManager mSensorManager;

    TextView tvHeading;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        // our compass image
        image = (ImageView) findViewById(R.id.imageViewCompass);

        // TextView that will tell the user what degree is he heading
        tvHeading = (TextView) findViewById(R.id.tvHeading);

        // initialize your android device sensor capabilities
        mSensorManager = (SensorManager) getSystemService(SENSOR_SERVICE);
    }

    @Override
    protected void onResume() {
        super.onResume();

        // for the system's orientation sensor registered listeners
        mSensorManager.registerListener(this, mSensorManager.getDefaultSensor(Sensor.TYPE_ORIENTATION),
                SensorManager.SENSOR_DELAY_GAME);
    }

    @Override
    protected void onPause() {
        super.onPause();

        // to stop the listener and save battery
        mSensorManager.unregisterListener(this);
    }

    @Override
    public void onSensorChanged(SensorEvent event) {

        // get the angle around the z-axis rotated
        float degree = Math.round(event.values[0]);

        tvHeading.setText("Heading: " + Float.toString(degree) + " degrees");

        // create a rotation animation (reverse turn degree degrees)
        RotateAnimation ra = new RotateAnimation(
                currentDegree,
                -degree,
                Animation.RELATIVE_TO_SELF, 0.5f,
                Animation.RELATIVE_TO_SELF,
                0.5f);

        // how long the animation will take place
        ra.setDuration(210);

        // set the animation after the end of the reservation status
        ra.setFillAfter(true);

        // Start the animation
        image.startAnimation(ra);
        currentDegree = -degree;

    }

    @Override
    public void onAccuracyChanged(Sensor sensor, int accuracy) {
        // not in use
    }
}

3.2 activity_main.xml – Our layout file. Wrapped in RelativeLayout, the TextView is used to display the user’s current heading. The ImageView contains the compass image which is being animated like a compass using the code in our MainActivity.java

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="#fff" >

    <TextView
        android:id="@+id/tvHeading"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_centerHorizontal="true"
        android:layout_marginBottom="40dp"
        android:layout_marginTop="20dp"
        android:text="Heading: 0.0" />

    <ImageView
        android:id="@+id/imageViewCompass"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_below="@+id/tvHeading"
        android:layout_centerHorizontal="true"
        android:src="@drawable/img_compass" />

</RelativeLayout>

3.3 Some notes

1. My app orientation is locked to portrait mode.
2. There are no special permissions in the Manifest file.
3. North Magnetic Pole is the point on the surface of Earth’s
Northern Hemisphere.
4. True north, or the geodetic north, is the direction along the earth’s surface towards the geographic North Pole.
5. Android SensorManager uses the magnetic North Pole.

5.0 Download Source Code

You can get the source code by following the whole, well detailed and free tutorial above. But isn’t it more convenient if you can just download the complete source code we used, and play around it?

There’s a small fee in getting the complete source code, it is small compared to the:

✔ Value or skill upgrade it can bring you, or YES
✔ Income you can get from your website project or business. YES
✔ Precious time you save. YES

Buy now

5.0 Further Readings

This can help you learn more about creating compass in android code. You can visit them and do more customizations!

1. Android SensorManager
2. Android RotateAnimation
3. Android Motion Sensors
4. Magnetic North Pole vs. Geographic North Pole
